OTTO ARC TPWH-C-2 ORBITAL WELD HEAD 1/2 - 2" OD

🔥 Introducing the Otto Arc C-2 Orbital Weld Head The Otto Arc C-2 series orbital weld heads deliver consistent and repeatable fusion (GTAW/TIG) welds for tubes, thin wall pipes, and fittings from ½” up to 2.0″ (50.8 mm) OD and standard wall thicknesses up to 0.160″ (4 mm).

Its narrow profile design is an ultimate solution for confined spaces, high-density installations, and fitting-to-fitting welds, making previously challenging work routine.

✨ Precision and Performance for High-Purity Applications For extra convenience and unmatched precision, the C-Series weld heads come equipped with an independent, two-sided collet clamping system. Precision machined and engineered, this mechanism easily adjusts to any minor diameter discrepancy, providing strong, concentric clamping force for flawless alignment every time and eliminating the need for tack welding.

Additionally, the weld head features internal water-cooling, making it a robust solution for continuous, high-duty-cycle operations.

🔩 Versatility and Support The Otto Arc C-2 is a cornerstone model for small diameter tube, with an optimal OD range of 0.25″ to 2.0″. Its suitability makes it ideal for diverse high-purity applications in industries like Semiconductor, Biopharmaceutical, and Aerospace.

A full line of accessories is available to maximize performance:

*Flush Collets for clamping close to the tangent on bends or near fittings.

*Extended Collets for maximum tube-to-tube alignment capability.

*Bench Mount Brackets for stable shop operation.

*Extension Hose packs from 25’ to 100’+ for maximum reach and flexibility from the powersource

Compatible with Arc-180 Arc-220

The Otto Arc C-2 orbital welding equipment delivers reliable, repeatable quality for your most demanding fusion welding projects.
