0.25 in. collet for Orbitalum Orbiweld 38S weld head

Custom Sized Collet Program: Orbitalum Orbiweld 38S

Tailor-Made Clamping Solutions for Non-Standard Tubing and Pipe Sizes

When standard, off-the-shelf collet sizes don’t match your project’s exact tubing dimensions, our Custom Sized Collet Program steps in. Starting with our standard collets for the Orbitalum Orbiweld 38S enclosed orbital weld head, you can get any size you need delivered quickly.

Key Features

• Infinite Size Flexibility: We machine collets to any exact metric or imperial dimension that fit the Orbiweld 38S weld head 0.110 inches to 1.5 inches (3mm-39mm) range.
• Ultra-Precision Tolerances: Every custom collet is machined to a tolerance of $\pm 0.001$ inches, guaranteeing an identical, concentric grip around your workpiece to prevent misalignment and scratching of electropolished tube
• Matching EDM Cuts: EDM cuts are added to make a built-in spring. This allows clamping of slightly oval or oversized/undersized tube.
• Direct Orbiweld 38S Compatibility: Designed to drop right into your existing Orbiweld 38S housing, matching OEM specifications for quick change-outs without modifying your weld head.

Program Requirements & Ordering Details

It’s very simple. Tell us the OD of your tube, we provide flat rate pricing and custom collets in 2-3 weeks:

⚠️ Minimum Order Quantity (MOQ): * 2 sets (enough for both sides of the 38S weld head). Volume discount if ordering 6 or more sets at the same time.

Lead Time: 2-3 Weeks lead time from time of order confirmation.

How to Order

1. Specify Your Outer Diameter (OD): Provide your exact target OD in decimals of an inch or millimeters.
2. Select Quantity: Ensure your order meets the minimum requirement (2 sets or 1 full head setup).
3. Production & Delivery: Once specifications are confirmed, your custom-milled and EDM-cut collets will move directly into production.
